B.O.D. Incubator
Introduction :
"LI" make Laboratory B.O.D. Incubator is designed & fabricated to suit various I.S. standards to meet requirements of Bio Chemical Oxygen demand test equipment in the growing field of Medical, Agricultural, Industrial, Research Laboratories, Storage Sensitive Culture, Vaccines, Culture of Bacteria, Microorganism, Serum Incubation, Seed Germination & Various Industries.
"LI" make Laboratory B.O.D. Incubator is designed & fabricated to suit various I.S. standards to meet requirements of Bio Chemical Oxygen demand test equipment in the growing field of Medical, Agricultural, Industrial, Research Laboratories, Storage Sensitive Culture, Vaccines, Culture of Bacteria, Microorganism, Serum Incubation, Seed Germination & Various Industries.
Copyrighted By Laboratoryinstruments.co.in . ALL RIGHT RESEREVED 2010
Develop By Advancewebdesigner
Specification
•Temperature range: 5.0°C to 60.0°C. Accuracy / Uniformity: ±0.5°C/±1°C
•Temperature display: Digital LED 3˝ digit
•Control: Microprocessor based PID control. With Auto tune CE marked
•Resolution: 0.1°C
•Temperature sensor: PT – 100
•Heating: ‘U’ shaped Nichrome wire heater in SS sheathing
•Cooling: CFC free Kirloskar make compressor utilizing R 134A eco friendly refrigerant, with condenser, motor and relay
•Air circulation: Flange motor with impeller / blower
•Construction: Double wall, with insulation, outer door key lockable, inner glass viewing door
•Chamber illumination: Fluorescent light with door switch
•Safety features
: High temperature safety cut off
: Electrical overload cut off relay for compressor
: Time delay for compressor switch ON
: Electrical circuit breaker
•Feet: Castor wheels
•Trays: SS wire mesh heavy duty
•Electrical: 230V / 15A / 50 Hz
•Temperature range: 5.0°C to 60.0°C. Accuracy / Uniformity: ±0.5°C/±1°C
•Temperature display: Digital LED 3˝ digit
•Control: Microprocessor based PID control. With Auto tune CE marked
•Resolution: 0.1°C
•Temperature sensor: PT – 100
•Heating: ‘U’ shaped Nichrome wire heater in SS sheathing
•Cooling: CFC free Kirloskar make compressor utilizing R 134A eco friendly refrigerant, with condenser, motor and relay
•Air circulation: Flange motor with impeller / blower
•Construction: Double wall, with insulation, outer door key lockable, inner glass viewing door
•Chamber illumination: Fluorescent light with door switch
•Safety features
: High temperature safety cut off
: Electrical overload cut off relay for compressor
: Time delay for compressor switch ON
: Electrical circuit breaker
•Feet: Castor wheels
•Trays: SS wire mesh heavy duty
•Electrical: 230V / 15A / 50 Hz
STD Model GMP Model
• Outer cabinet mild steel powder coated . Outer cabinet SS 304 grade dull matt finish
• Inner chamber stainless steel 304 grade • Inner chamber stainless steel mirror finish
• Outer cabinet mild steel powder coated . Outer cabinet SS 304 grade dull matt finish
• Inner chamber stainless steel 304 grade • Inner chamber stainless steel mirror finish
Pre Installation Mandatory Requirement :
(Guarantee void incase of non compliance)
a) Room temperature around machine preferably at 25°C with air conditioning or a well ventilated room with exhaust fan. However surrounding temperature should not exceed 30°C
b) Stabilized input voltage of 230V AC 20 Amps. Use of servo controlled stabilizer is recommended
(Guarantee void incase of non compliance)
a) Room temperature around machine preferably at 25°C with air conditioning or a well ventilated room with exhaust fan. However surrounding temperature should not exceed 30°C
b) Stabilized input voltage of 230V AC 20 Amps. Use of servo controlled stabilizer is recommended
